3.0V Monochrome LCD Display 16 Character 2 Line LCD Display Screen

Place of Origin : China

Brand Name : BBI

MOQ : 1000

Price : DISCUSSABLE

Packaging Details : CARTON

Delivery Time : 3-4WEEKS

Payment Terms : T/T

Supply Ability : 100000/MONTH

Certification : ISO9001 RoHS

Name : Monochrome LCD Display

Display Type : HTN, POSITIVE ,TRANSFLECTIVE

Drive ic : ST7565R

Color : Monochrome

Viewing Direction : 12.00 O’clock

Backlight Type : LED

Number Of Characters : 16 Characters X 2 Lines

Contact Now

3.0V Monochrome LCD Display 16 Character 2 Line LCD Display Screen
3.0V Monochrome LCD Display 16 Character 2 Line LCD Display Screen
General Specification
P/N SDH-13304-HP-4
Power Supply 3.0V
Display Type HTN, POSITIVE, TRANSFLECTIVE
Viewing Direction 12.00 O'clock
LCD Driving Method 1/4 Duty, 1/3 Bias, 3.0V
Driver IC ST7565R
Input Data Parallel 6800 Series MPU Interface / Parallel 8080 Series MPU Interface / Serial 4-Line SPI Interface
Module Size (W*H*T) 170*57.6mm
Glass Thickness 1.1
Connector PIN
3.0V Monochrome LCD Display 16 Character 2 Line LCD Display Screen 3.0V Monochrome LCD Display 16 Character 2 Line LCD Display Screen
Packaging & Shipping
Packaging: Carton boxes, Cupboard, EPE, Blister Tray. Packaging method depends on product size and customer requirements, which may vary by country. 3.0V Monochrome LCD Display 16 Character 2 Line LCD Display Screen
Shipping: Express via DHL, Fedex, EMS, UPS, air shipping, or sea shipping. Any shipping method preferred by customer. 3.0V Monochrome LCD Display 16 Character 2 Line LCD Display Screen
Payment Method: 3.0V Monochrome LCD Display 16 Character 2 Line LCD Display Screen
FAQ
  • I want the LCD display 8 digits and the outline size is 65x30x2.8mm?
    No problem. Please send us your specification/drawing paper. If unavailable, we can recommend suitable standard products or customize based on your requirements.
  • This LCD is just what we want, but it is big size, do you have any smaller size? And the display content need to be changed a little.
    For segment type LCD modules requiring size or content modifications, we need to create new tooling for a custom LCD glass module.
  • This LCD display is HTN type, but I want STN type, can you make?
    Yes, we can modify the display type according to your request.
  • I want customize a new LCD module. Can you do?
    Yes, we can. Please send your drawing paper or provide specifications including outline size, display information, glass thickness, polarizer, display type, connector mode, storage/operating temperature, supply voltage, viewing direction, and drive conditions.
  • What is leading time for tooling?
    Typically 15 to 25 days after drawing confirmation and tooling charge payment. Exact time will be confirmed upon drawing approval.
  • Can you send us samples for checking?
    Yes, sample orders are available.
  • What is the Leading Time?
    For standard products in stock: 1 day after payment. For special mass production: 15-30 days. We will inform you if we can finish earlier.
Our Services
  • Free repair within one year after shipment
  • Replacement within 30 days for product-related issues
  • Custom logo printing and model number labeling
  • Discounted shipping rates through our established partnerships
  • Professional technical support and responsive after-sales service
  • All products inspected and tested by engineers and QC/QA before shipment
  • 24-hour response to customer inquiries
  • Custom LCD display solutions based on your specifications or drawings
Product Applications
  • Household appliances: Refrigerators, air conditioners, fans, heaters, water heaters, electric blankets, air purifiers, washing machines, dryers, vacuum cleaners, microwave ovens, cookers, rice cookers, water dispensers, tea sets
  • Communication equipment: Telephones, interphones, fax machines, wireless wifi
  • Automotive electronics: On-board entertainment systems, car navigation, audio systems, reverse radar, cameras, anti-theft devices
  • Instruments: Water meters, electric meters, multimeters, electronic scales, pressure meters, temperature meters, flow meters, display instruments
  • Fitness equipment: Treadmills, exercise bikes, training devices, pedometers, weighing scales
  • Financial: Tax control cash machines, POS systems, cheque printers, banknote counting machines
  • Consumer electronics: MP3/MP4 players, DVD players, electronic dictionaries, calculators, electronic clocks
Features: High resolution, high definition, high brightness, cost-effective, energy efficient, wide temperature range (positive/negative), suitable for various environmental conditions.
